CMOS VCTCXO

A voltage-controlled temperature-compensated quartz crystal oscillator is a crystal oscillator with both temperature compensation and voltage control functions. When the operating temperature range is wide and the frequency stability is high, the frequency-temperature characteristics need to be temperature compensated to improve its frequency-temperature stability.

Model	Voltage	Frequency	Dimension	Operating Temp	Frequency Tolerance	Output	Datasheet
YSV322PT	2.5/ 3.3V	10-1500MHz	3.2x2.5 7.0x5.0	-40℃~+85℃	±1ppm ±2.5ppm	PECL LVDS	Download
YSV350TP	1.8/ 2.5/ 3/ 3.3V	6~52MHz	3.2x2.5 5.0x3.2 7.0x5.0	-40℃~+85℃	±0.5ppm ±1.5ppm ±2.5ppm	LVPECL LVDS	Download
YSV531PT	2.5/ 3.3V	10-250MHz	3.2 x 2.5 7.0 x 5.0	-40℃~+85℃	±2.5ppm	CMOS	Download
