KHz Crystals

32.768KHz is one kind of the clock crystal frequency for timing device, mainly used on the small communication devices. YXC supports DIP 2 pin through hole type tuning fork as well as SMD/SMT type crystal resonators. Its market-favored size is: 3.2 x 1.5 mm, 7.0 x 1.5 mm, 8.0 x 3.8 mm, with its most used load capacitance: 6pF, 7pF, 9pF, 12.5pF.
Picture Model Frequency Dimension Load Capacitance Operating Temp Frequency Tolerance Datasheet
 YSX1610SK YSX1610SK 32.768KHz 1.6 x 1.0 x 0.50 mm 6pF, 7pF, 9pF, 12.5pF -40℃~+85℃ ±20ppm Download
YSX2012SK YSX2012SK 32.768KHz 2.0 x 1.2 x 0.6 mm 6pF, 7pF, 9pF, 12.5pF -40℃~+85℃ ±20ppm Download
YST310S YST310S 32.768KHz 3.2 x 1.5 x 0.75 mm 6pF, 7pF, 9pF, 12.5pF -40℃~+85℃ ±10ppm, ±20ppm Download
YSX146GA YSX146GA 32.768KHz 7.0 x 1.5 x 1.4 mm 6pF, 7pF, 9pF, 12.5pF -40℃~+85℃ ±10ppm, ±20ppm Download
YSX306GA YSX306GA 32.768KHz 8.0 x 3.8 x 2.5 mm 6pF, 7pF, 9pF, 12.5pF -40℃~+85℃ ±20ppm Download
YT-26 YT-26 32.768KHz 2.0 x 6.0 mm 12.5pF, or specify -20℃~+70℃ -40℃~+85℃ ± 5ppm, ±10ppm Download
YT-38 YT-38 32.768KHz 3.0 x 8.0 mm 12.5pF, or specify -20℃~+70℃ -40℃~+85℃ ±5ppm ±10ppm Download
FC-135 FC-135 32.768KHz 3.2 x 1.5 mm 7pF, 9pF, 12.5pF -40℃~+85℃ ±20ppm ±25ppm Download
MC-146 MC-146 32.768KHz 7.0 x 1.5 mm 7pF, 12.5pF -40℃~+85℃ ±10ppm ±20ppm Download
MC-306 MC-306 32.768KHz 8.0 x 3.8 mm 7pF, 9pF, 12.5pF, or specify -40℃~+85℃ ±20ppm ±50ppm Download
FC-135R FC-135R 32.768KHz 3.2 x 1.5 mm 7pF, 9pF, 12.5pF -40℃~+85℃ ±20ppm ±25ppm Download
FC-12M FC-12M 32.768KHz 2.0 x 1.2 mm 12.5pF -40℃~+85℃ ±10ppm ±20ppm Download
FC2012AN FC2012AN 32.768KHz 2.0 x 1.2 mm 9pF, 12.5pF -40℃~+105℃ ±20ppm Download
FC1610AN FC1610AN 32.768KHz 1.6 x 1.0 mm 9pF, 12.5pF -40℃~+85℃ ±20ppm Download
YT-26F YT-26F 32.768KHz 2.0 x 6.0 mm 12.5pF -40℃~+85℃ ±20ppm Download
YT-26FA YT-26FA 32.768KHz 2.5 x 6.0 mm 12.5pF -40℃~+85℃ ±20ppm Download
