YOV5050DP

* Temperature stability ≤±0.01ppb (-40~+70℃)
* Short-term stability ≤1.5E-13 (1s)
* 1Hz offset ≤-120dBc/Hz@10MHz
* Supply voltage: 5V,12 V

Datasheet Contact Us
Parameter Table
Sample
Specifications :
Specification Value
Frequency Range 5~20 MHz
Temperature Stability ≤ ±0.01 ppb (best achievable, +40°C to +70°C)
Operating Temperature −40°C ~ +70°C
Output Type Sine Wave / HCMOS
Short-Term Stability < 1.5 × 10⁻¹³ @ 1 s
Operating Temperature −165 dBc/Hz min. (10 MHz)
Package 50.8 × 50.8 × 15.0 mm


Features:
♦ Ultra-high frequency stability as tight as ±0.01 ppb over +40°C to +70°C.
♦  Ultra-low phase noise of −165 dBc/Hz at 1 kHz offset (10 MHz).

♦  Excellent short-term stability of less than 1.5 × 10⁻¹³ at 1 second.
♦  Frequency range from 5 MHz to 20 MHz.
♦  Sine wave and HCMOS output options.
♦  Supply voltage options of 5 V and 12 V.
♦  Low aging rate of ≤ ±5 × 10⁻¹¹ per day.
♦  Warm-up time of less than 15 minutes.
♦  Operating temperature range from −40°C to +70°C.



Applications:

♦  Satellite Timing

♦  Communication Base Stations



Submit

Voltage : 5V,12V

Frequency : 5~20MHz

Dimension : 50.8x50.8x15

Operating Temp : -40~+70℃

Frequency Tolerance : ≤±0.01ppb@-40~+70℃

Output : Sine Wave / HCMOS

Series : Ultra-Low Noise, Ultra-High Stability OCXO
