* Multiple voltage options available (1.8V, 2.5V, 3.3V)
* Suitable for high-temperature environments (-40~+85℃)
* Diverse output types (LVPECL, LVDS, HCSL, LPHCSL, LVDS-Boost (800mV typ.), CML)
* Ultra-low jitter: 0.069ps typ.@156.250MHz
* Packages: 2.5x2.0mm, 3.2x2.5mm
Voltage : 1.8/ 2.5/ 3.3V
Frequency : 200KHz~1500MHz
Dimension : 2.5 x 2.0 3.2 x 2.5
Operating Temp :
Frequency Tolerance : ±50ppm
Output : LVPECL、LVDS、HCSL、LPHCSL、LVDS-Boost(800mV typ.)、CML
